NAT Tracks example with RLAT – 2017

With the new (ish) RLAT Tracks, the standard NAT Track picture looks different these days. We thought we’d draw one out so you can see the RLAT Tracks. This example is the Westbound Tracks today, February 24th 2017. The RLAT Tracks are C, D, and E.

The neat plotting chart that this is drawn on is from Flight Service Bureau and available here.

Picture first (click for big version), Track message follows:

Westbound NAT Tracks 24th February, 2017.

232034 EGGXZOZX
(NAT-1/2 TRACKS FLS 310/390 INCLUSIVE
FEB 24/1130Z TO FEB 24/1900Z
PART ONE OF TWO PARTS-
A RESNO 56/20 57/30 57/40 56/50 JANJO
EAST LVLS NIL
WEST LVLS 310 320 330 340 350 360 370 380 390
EUR RTS WEST NIL
NAR NIL-
B DOGAL 55/20 56/30 56/40 55/50 LOMSI
EAST LVLS NIL
WEST LVLS 310 320 330 340 350 360 370 380 390
EUR RTS WEST NIL
NAR NIL-
C MALOT 54/20 55/30 55/40 54/50 NEEKO
EAST LVLS NIL
WEST LVLS 310 320 330 340 350 360 370 380 390
EUR RTS WEST NIL
NAR NIL-
D TOBOR 5330/20 5430/30 5430/40 5330/50 PELTU
EAST LVLS NIL
WEST LVLS 350 360 370 380 390
EUR RTS WEST NIL
NAR NIL-
E LIMRI 53/20 54/30 54/40 53/50 RIKAL
EAST LVLS NIL
WEST LVLS 310 320 330 340 350 360 370 380 390
EUR RTS WEST NIL
NAR NIL-
END OF PART ONE OF TWO PARTS)


232035 EGGXZOZX
(NAT-2/2 TRACKS FLS 310/390 INCLUSIVE
FEB 24/1130Z TO FEB 24/1900Z
PART TWO OF TWO PARTS-
F DINIM 52/20 53/30 53/40 52/50 TUDEP
EAST LVLS NIL
WEST LVLS 310 320 330 340 350 360 370 380 390
EUR RTS WEST NIL
NAR NIL-
REMARKS.
1.TMI IS 055 AND OPERATORS ARE REMINDED TO INCLUDE THE
TMI NUMBER AS PART OF THE OCEANIC CLEARANCE READ BACK.
2.ADS-C AND CPDLC MANDATED OTS ARE AS FOLLOWS
TRACK A 350 360 370 380 390
TRACK B 350 360 370 380 390
TRACK C 350 360 370 380 390
TRACK D 350 360 370 380 390
TRACK E 350 360 370 380 390
TRACK F 350 360 370 380 390
END OF ADS-C AND CPDLC MANDATED OTS
3.RLATSM OTS LEVELS 350-390. RLATSM TRACKS AS FOLLOWS
TRACK C
TRACK D
TRACK E
END OF RLATSM OTS
4.FOR STRATEGIC LATERAL OFFSET AND CONTINGENCY PROCEDURES FOR OPS IN
NAT FLOW REFER TO NAT PROGRAMME COORDINATION WEBSITE WWW.PARIS.ICAO.INT.
SLOP SHOULD BE STANDARD PROCEDURE, NOT JUST FOR AVOIDING WX/TURB.
5.80 PERCENT OF GROSS NAVIGATION ERRORS RESULT FROM POOR COCKPIT
PROCEDURES. CONDUCT EFFECTIVE WAYPOINT CHECKS.
6.OPERATORS ARE REMINDED THAT CLEARANCES MAY DIFFER FROM THE FLIGHT PLAN,
FLY THE CLEARANCE.
7.UK AIP. ENR 2.2.4.2 PARA 5.2 STATES THAT NAT OPERATORS SHALL FILE
PRM'S.
8.FLIGHTS REQUESTING WESTBOUND OCEANIC CLEARANCE VIA ORCA DATALINK
SHALL INCLUDE IN RMK/ FIELD THE HIGHEST ACCEPTABLE FLIGHT LEVEL WHICH CAN
BE MAINTAINED AT OAC ENTRY POINT.
9.ALL ADSC CPDLC EQUIPPED FLIGHTS NOT LOGGED ON TO A DOMESTIC ATSU
PRIOR TO ENTERING THE SHANWICK OCA MUST INITIATE A LOGON TO EGGX BETWEEN 10
AND 25 MINUTES PRIOR TO OCA ENTRY.-
END OF PART TWO OF TWO PARTS)
