The Big SATVOICE Question

By OPSGROUP Team

0Shares


SATVOICE. Satellite voice communications. The most expensive phone call you can make (probably). But also an incredibly useful bit of kit to have onboard because it lets you talk to folk much further away than VHF and HF generally do.

But just because you have it doesn’t mean you can count in it, at least not as one of your official LRCS (that means longe range communication system in case you didn’t know).

So, there is a great system which lets you talk over long ranges, but isn’t always approved as a long range communication system?

Before we get to the ‘why not?’…

A quick recap on what SATVOICE is.

It is exactly what the name suggests – a system that allows voice communications, via satellites. So your voice message zooms up, bounces off the satellite and zooms back down to wherever you’re aiming it. And because it heads up and then down, it can go further.

OK, it might be a little more scientific than that, but that’s a basic description.

There are some things it doesn’t do though.

It doesn’t replace VHF or HF as a primary means of communication. One of the reasons being not every ATC has the facilities to receive or call you via it.

It doesn’t always work at high latitudes because not all satellite providers have coverage up there. Iridium satellites are ok – they are in low earth orbits rather than geostationary ones so they don’t get that SATCOM shadow you might have heard mentioned.

It doesn’t always avoid the impacts space weather – the stuff that affects HF, particularly at high latitudes, can also disrupt your satellite comms.

SATCOM frequency range.

You probably know all this already.

If you don’t then you can read some more about it here.

Now, let’s get down to the real question…

Can you count your SATVOICE system as a LRCS?

OK, well firstly where do you actually need LRCS?

In short, anytime you’ll be flying for extended periods over watery regions or remote regions where VHF stations probably aren’t possible (so anytime you’ll be outside the ‘line of sight’ of ATC). Like the NAT HLA for example.

In these regions you generally require two LRCS, and one of these must be HF. Where you only require one, this must be HF.

The FAA published this which covers some info on comms requirements in oceanic airspace.

They also published this – AC 91-70B – which is the full guidance on Oceanic and Remote Continental Airspace Operations, and this has a whole section on SATVOICE that is pretty handy.

So if one LRCS is HF, what does the other need to be?

Because of frequency congestions and solar conditions that often make HF annoying to use in oceanic and remote spots, other systems can be approved as an LRCS. It doesn’t only have to be HF.

CPDLC is on option that is considered suitable. The FANS 1/A+ with its RCP 240 system satisfies the requirements.

And (finally) what about my SATVOICE system?

Well… just because you have SATVOICE doesn’t mean it meets the criteria…

This hasn’t answered the question at all!

No, we know. We’re trying…

Basically, it has to meet a whole bunch of criteria in order to be IAW 20-150B certified, and this certification should be reflected in your MMEL/MEL.

In case you don’t know what that is, the info is all covered in this FAA advisory.

AC 20-150B

There is a whole looong list of requirements. We won’t list ’em all here, but some of the top ones are:

  • Whatever you say on SATVOICE has to be recordable on the CVR
  • You have to have considered whether it will work if you’re in a “load shed” situation (ie will it still be available in some hideous emergency power lever situation?)
  • It has to be able to tell the pilots things like if its broken, if someone is trying to call on it, etc
  • It has to meet certain RCP criteria (RCP400)

RCP monitoring and alerting criteria

  • Oh yeah, and it has to have priority, preemption and precedence abilities (PPP).

Say what?

PPP. Priority, preemption and precedence. Preemption is defined by the FAA as the “immediate and automatic seizure of resources allocated to a lower priority call”.

It might be easier to look at this table, but in short calls have to be routed through the CMY and filtered according to this –

If it can’t prioritise, it won’t be certified.

Tell me which ones are?

Well, that is a very big question and really not something we can answer. Yep, we made you read all that and still don’t actually have an answer for you.

What we do know, because other people told us, it that:

  • Typical AirCell installations do not meet the criteria
  • Latitude SkyNode S200-12 ATC Safety Voice Systems generally do
  • The Aspire 300 SATCOM system also generally does
  • And there are possibly a whole bunch others but the surest way to find out is to talk to the manufacturers and ask them directly.

Anything else?

Well, we definitely don’t want to get your hopes up, but a little birdie told us that a change might be coming to the “one of the LRCS systems must be HF” requirement. This is in part due to the reliability and practicality of SATVOICE systems.

When this will happen we ain’t sure, but listen out.

image_pdf

More on the topic:

More reading:

OPSGROUP Team

OPSGROUP Team

Question for us? Write to blog.team@ops.group.

7 Comments

  • Joe says:

    Will 2 HF Radios meet the 2 LRCS requirement (outside of VHF areas) in the NAT or does the 2nd LRCS need to be either FANS 1/A CPDLC or SATVOICE? Wording in NAT Doc 007 is a bit confusing. Thank you for putting this information out there. You guys do great work

    • Joe says:

      And for clarification, I’m talking about the non-DLM portions of the HLA (NY Oceanic East) or above/below NAT HLA/DLM as another example. I realize the second LRCS could be covered with CPDLC in the NAT DLM. Thanks in advance!

  • Douglas Snow says:

    The FAA also wrote this info, specifically dealing with Iridium SATCOM systems; as of when they wrote this, an Iridium-based SATCOM system didn’t meet the requirement for Safety Services (a specific requirement in the UK AIP). I know Iridium is working on that ability which will prompt changes in MMEL PL-106 for HF, the UK AIP, and a few OpSpecs as well.

    https://www.faa.gov/other_visit/aviation_industry/airline_operators/airline_safety/info/all_infos/media/2015/InFO15008.pdf

  • James Pyne says:

    SATVOICE approval is down to the registry your aircraft is on.

    FAA, for example, has strict requirements.

    Also OEMs will be able to tell you whether your system is certified for SATVOICE requirements.

  • Rahul Pratap says:

    Jeppco ATC chapter and also avbl on airway charts along the FIR boundaries.

  • Vialard L says:

    Hello
    does someone know where to find the list of ATC phone numbers?
    I have an old directory from Collins but it is quite complicated to find an update?
    thanks

    • Bradley Crosier says:

      Jeppesen Airway manual – General volume, Enroute section: “INMARSAT Security Numbers (Short Codes) and SATCOM Voice (PSTN). There is a table listing the numbers by region of the world, then country, then ATC facility and FIR.
