SATVOICE. Satellite voice communications. The most expensive phone call you can make (probably). But also an incredibly useful bit of kit to have onboard because it lets you talk to folk much further away than VHF and HF generally do.

But just because you have it doesn’t mean you can count in it, at least not as one of your official LRCS (that means longe range communication system in case you didn’t know).

So, there is a great system which lets you talk over long ranges, but isn’t always approved as a long range communication system?

Before we get to the ‘why not?’…

A quick recap on what SATVOICE is.

It is exactly what the name suggests – a system that allows voice communications, via satellites. So your voice message zooms up, bounces off the satellite and zooms back down to wherever you’re aiming it. And because it heads up and then down, it can go further.

OK, it might be a little more scientific than that, but that’s a basic description.

There are some things it doesn’t do though.

It doesn’t replace VHF or HF as a primary means of communication. One of the reasons being not every ATC has the facilities to receive or call you via it.

It doesn’t always work at high latitudes because not all satellite providers have coverage up there. Iridium satellites are ok – they are in low earth orbits rather than geostationary ones so they don’t get that SATCOM shadow you might have heard mentioned.

It doesn’t always avoid the impacts space weather – the stuff that affects HF, particularly at high latitudes, can also disrupt your satellite comms.

You probably know all this already.

If you don’t then you can read some more about it here.

Now, let’s get down to the real question…

Can you count your SATVOICE system as a LRCS?

OK, well firstly where do you actually need LRCS?

In short, anytime you’ll be flying for extended periods over watery regions or remote regions where VHF stations probably aren’t possible (so anytime you’ll be outside the ‘line of sight’ of ATC). Like the NAT HLA for example.

In these regions you generally require two LRCS, and one of these must be HF. Where you only require one, this must be HF.

The FAA published this which covers some info on comms requirements in oceanic airspace.

They also published this – AC 91-70B – which is the full guidance on Oceanic and Remote Continental Airspace Operations, and this has a whole section on SATVOICE that is pretty handy.

So if one LRCS is HF, what does the other need to be?

Because of frequency congestions and solar conditions that often make HF annoying to use in oceanic and remote spots, other systems can be approved as an LRCS. It doesn’t only have to be HF.

CPDLC is on option that is considered suitable. The FANS 1/A+ with its RCP 240 system satisfies the requirements.

And (finally) what about my SATVOICE system?

Well… just because you have SATVOICE doesn’t mean it meets the criteria…

This hasn’t answered the question at all!

No, we know. We’re trying…

Basically, it has to meet a whole bunch of criteria in order to be IAW 20-150B certified, and this certification should be reflected in your MMEL/MEL.

In case you don’t know what that is, the info is all covered in this FAA advisory.

AC 20-150B

There is a whole looong list of requirements. We won’t list ’em all here, but some of the top ones are:

• Whatever you say on SATVOICE has to be recordable on the CVR
• You have to have considered whether it will work if you’re in a “load shed” situation (ie will it still be available in some hideous emergency power lever situation?)
• It has to be able to tell the pilots things like if its broken, if someone is trying to call on it, etc
• It has to meet certain RCP criteria (RCP400)

• Oh yeah, and it has to have priority, preemption and precedence abilities (PPP).

Say what?

PPP. Priority, preemption and precedence. Preemption is defined by the FAA as the “immediate and automatic seizure of resources allocated to a lower priority call”.

It might be easier to look at this table, but in short calls have to be routed through the CMY and filtered according to this –

Tell me which ones are?

Well, that is a very big question and really not something we can answer. Yep, we made you read all that and still don’t actually have an answer for you.

What we do know, because other people told us, it that:

• Typical AirCell installations do not meet the criteria
• Latitude SkyNode S200-12 ATC Safety Voice Systems generally do
• The Aspire 300 SATCOM system also generally does
• And there are possibly a whole bunch others but the surest way to find out is to talk to the manufacturers and ask them directly.

Anything else?

Well, we definitely don’t want to get your hopes up, but a little birdie told us that a change might be coming to the “one of the LRCS systems must be HF” requirement. This is in part due to the reliability and practicality of SATVOICE systems.

When this will happen we ain’t sure, but listen out.

SATVOICE. Easy peasy. Well, until until you’re routing from San Francisco to Tokyo for the first time in your shiny new G550 and its 2am, you’re passing  W177°, you think you filed M3 but aren’t sure if you’re actually M2, and there is a full moon and now you’re not so sure anymore…

Here is a look at some common questions about SATVOICE which we have seen come up.

Feel free to send us more. We aren’t experts but know one folk who are.

What is SATVOICE?

Satellite voice communications. Sometimes it is lumped in with SATCOM but this can include messaging systems as well (your Datalink type things). The ‘VOICE’ bit is the giveaway – we are specifically talking about talking.

What is it used for?

Communicating.

More specifically, communicating over big areas where there are not many ground stations (which you need for VHF comms). SATVOICE systems *can be (and note the asterix there) used as a Long Range Communications System (LRCS).

So, SATVOICE is talking, via satellites, and it can be used to do things like give voice position reports. It is also sometime used as a backup when HF is not functioning. What it is not (currently) is a replacement for HF. Just as CPDLC isn’t allowed as a replacement because it is not suitable for emergency of non-routine comms.

Where can I use it?

Anywhere where there is satellite coverage. And anywhere where ATC are using it as a means of LRCS. They may not be capable.

For example, the FAA provide Inmarsat and Iridium SATVOICE services for air-to-ground (and vice versa) calls directly with Oakland, NY and Anchorage ARTCCs, and New York and San Fran radio. These are, again, supplemental to HF which means they don’t expect you to use it unless there is some issue with HF. Times of bad HF propagation like HF blackouts would be a good time to give SATVOICE a go.

Right now, SATVOICE is not the primary means of communication in many spots. VHF and HF remain the main ones, with Datalink comms (CPDLC). So it is unlikely you will be using it all that much, unless something else is not working. When you are in CPDLC/ADS-C airspace, the controller is normally going to communicate via Datalink. They might elect to use SATVOICE, but it is not a replacement for ADS-C/CPDLC or HF/VHF.

So you also need to check out the airspace you’re flying into. The AICs will generally contain info on whether an airspace/ ATS has SATVOICE capability.

ICAO says – “Some ANSPs may allow the flight crew to use SATVOICE only for certain types of communications (e.g. of an urgent nature) or may place limitations on use of SATVOICE directly to the controller. Other ANSPs may allow its use only as an additional capability to existing radio equipment carriage requirements.” (Section 3.4, SVGM).

So, where CAN’T I use it?

Inmarsat satellites are geostationary and orbit around the equator which means above a latitude of 82° North (and South) you are in a satellite-less areas because of the (often debated, definitely real) curvature of the earth means a lack of line of sight which is required for your communications to be able to bounce back and forth from the satellites.

Some manuals suggest you might start to run into a bit of trouble from 70°N, and that trouble is most pronounced on the W120 longitude. It is also dependant on atmospheric conditions, where your antenna is and what services are contracted though.

Iridium satellites do not suffer the same SATCOM shadow because they operate in a low earth (as opposed to geostationary) orbit.

What do I need to do to use it then?

Go back up to our bit about having an approved system and it being in your MEL…

And read this bit as well.

So, you need it in your MEL/MMEL, and what that means is having a system which meets the requirements laid out by your authority.

The FAA put out this info on getting approved. AC 20-150B – ‘Airworthiness Approval of Satellite Voice (SATVOICE) Equipment Supporting Air Traffic Service (ATS) Communication.

It is an AIC about getting airworthiness approval for SATVOICE, and contains all the design considerations, software requirements, minimum performance requirements, CVR, and a lot of other things you probably need to know about.

ICAO recommend that Operators need to establish policy and procedures for crew involved in SATVOICE ops. This includes descriptions of the system operating procedures, limitations, flight planning requirements, what to do if it does’t work… Check out section 3.3.3 of the ICAO SVGM manual for more on this.

In summary – your system needs to be approved. To be approved it needs to meet certain standards and criteria. You also need to have procedures and policy in place for the operation of the system.

Where is all the official info on this?

In ICAO Doc 9869, also known as the PBCS manual, also known as the GOLD manual (because its full title is Global Operational Data Link). You can find the 2017 edition of this in our Doc Library if you want to take a look.

Here is the ICAO SVGM (Satellite Voice Guidance Manual) which we mentioned.

Then there is ICAO Doc 7030 which contains regional supplementary procedures and will contain some info on Datalink, for example, over the North Atlantic.

I have the system and the approval, but need to find a number?

Well, this is where it can get a little tricky. There are different systems. Inmarsat and Iridium.

There is also MTSAT, the Japanese geostationary satellite network.

If you have Inmarsat satellite compatible system then you can use those SATCOM short codes (the six digit ones starting with a 4). You can also dial the 10-digit PSTN phone number. The 6 digit numbers are converted to the PTSN number as they wiggle through the Inmarsat system.

PTSN, incase you’re going to ask, is the Public Switched Telephone Network which is what the aeronautical SATVOICE system uses. So these are what you want to call via your Iridium system.

Numbers are generally to be found in places like the AICs, in your Jeppesen, LIDO, or whatever other chart and manual provider you are signed up to.

One tip, when you do dial up – don’t be yakking away like you’re on a normal telephone. The operator the other end is going to expect standard radio etiquette. Callsigns, readbacks and all that.

What do I put in my flight plan?

You need to include your SATVOICE capability and you do this in Item 10 by inserting either:

• M1 for Inmarsat RTF capability;
• M2 for MTSAT RTF capability;
• And/or an M3 for Iridium RTF capability.

In Item 18 you insert the aircraft registration and also the indicator code and the aircraft address expressed in the form of an alphanumerical code of 6 characters.

If you are operating through airspace requiring HF and yours is broken, then you may be able to file with only your SATVOICE system as the LRCS if it is a flight to return the aircraft for HF maintenance.

Again, just having a system and whacking the info about it onto a flight plan does not qualify you to use it. It needs to be approved.

What if I get a random SATVOICE call?

You should only act on the clearances or instructions given to you if a SATVOICE call has a priority level 2/High/Q12 or 1/EMG/Q15. You might have to disconnect and initiate a new call to get confirmation that it is something to act on, and not just some rogue person who has discovered a way to call you on it.

I am not signed up to any provider. Can I still just sort of call?

If you can answer this then please send us your info 🤷
